China AP80 Slices - Quality Products from Trusted Suppliers and Reliable Factory
Satellites Tracking
Channels
1408
GPS
L1C/A, L1C, L2C, L2P(Y), L5
GLONASS
L1, L2, L3*
Galileo
E1, E5a, E5b, E6
BDS
B1I, B2I, B3I, B1C, B2a, B2b
QZSS
L1C/A, L1C, L2C, L5, L6
NavIC/IRNSS
L5
SBAS
L1C/A
L-Band
B2B-PPP & E6-HAS
Accuracy
Real time kinematics (RTK)
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Initialization time: <5s (typical)
Initialization reliability: >99.9%
Vertical: 15 mm + 1 ppm RMS
Initialization time: <5s (typical)
Initialization reliability: >99.9%
Post-processing kinematics (PPK)
Horizontal: 3 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
Static
Horizontal: 2.5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
PPP
Horizontal: 5cm RMS | Vertical: 10cm RMS
DGPS
Horizontal: 0.4 m RMS | Vertical: 0.8 m RMS
Single Point
Horizontal: 1.5 m RMS | Vertical: 2.5 m RMS
Visual survey
Typical 2~4 cm, range 2~15 m (normal lighting conditions)
Laser survey
±8mm + 5mm/m (Tilt angle within 30°)
AR stakeout
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Position Frequency
1Hz, 2Hz, 5Hz, 10Hz, 20Hz
Time to first fix
Cold start: <45s
Hot start: <10s
Signal re-acquisition: <1s
Hot start: <10s
Signal re-acquisition: <1s
IMU tilt angle
0-120°
IMU tilt survey accuracy
≤2cm within 60° tilt angle
Camera
Number of cameras
2
Pixel
Global shutter 2MP & 5MP
Frame rate
30fps
Field of view
84°
Features
2MP front camera achieve visual measurements & laser aiming
5MP bottom camera achieve AR stakeout
5MP bottom camera achieve AR stakeout
Communication
UHF radio
2W Tx/Rx, 450-470 MHz
Working range is 8-15km in ideal environments
Working range is 8-15km in ideal environments
Protocol
TT450, TRIMMARK3, SOUTH, LORA
Link rate: 9600bps to 19200bps
Link rate: 9600bps to 19200bps
Wifi
802.11b/g/n/ac
Hotspot/Data Link
Hotspot/Data Link
Bluetooth
Bluetooth 5.2 classical/BLE proprietary dual-mode
NFC
NFC touch pairing
WebUI
Accessible via Wi-Fi
4G Cellular
Integrated full frequency multi band 4G modem
supports LTE-TDD/LTE-FDD/WCDMA/CDMA2000/UMTS/HSPA+/GSM/GPRS/EDGE
supports LTE-TDD/LTE-FDD/WCDMA/CDMA2000/UMTS/HSPA+/GSM/GPRS/EDGE
I/O port
• 1x USB Type-C port (Data download / Charging)
• 1x Antenna port (UHF antenna interface)
• 1x Sim card slot (Supports Nano-sim)
• 1x 5-pin Lemo port (RS-232)
• 1x Antenna port (UHF antenna interface)
• 1x Sim card slot (Supports Nano-sim)
• 1x 5-pin Lemo port (RS-232)
Data formats
RTCM 2.X, RTCM 3.X, RINEX, NMEA 0183 output, VRS, NTRIP
Data storage
32GB high speed memory
Electrical
Battery
Internal Li-on Battery 7.4V 7000mAh
Charging specs
USB Type-C fast charging
Operation time
Rover mode: 18 hours
Base mode: 7 hours
Static mode: 20 hours
Base mode: 7 hours
Static mode: 20 hours
Hardware
Size
125mm(W) × 88mm (H) / 4.92inch(W) × 3.46inch(H)
Weight
750g (1.65lb)
Front panel
0.96'' OLED color screen display, 2 LED lights, 2 physical buttons (switchable mode, data link)
Environments
Working temperature
-45°C to +75°C
Storage temperature
-55°C to +85°C
Humidity
100% non-condensation
Waterproof & Dustproof
IP67
Drop
Survive a 2-meter pole-drop
Vibration
IK08
Frequently Asked Questions
How many channels does this GNSS receiver support for satellite tracking?
The receiver is equipped with 1408 channels. It tracks a comprehensive range of constellations including GPS, GLONASS, Galileo, BDS, QZSS, NavIC/IRNSS, SBAS, and supports L-Band services (B2B-PPP & E6-HAS).
What is the typical accuracy for RTK and static positioning?
For Real-Time Kinematics (RTK), the accuracy is 8 mm + 1 ppm RMS horizontally and 15 mm + 1 ppm RMS vertically. For static measurements, it delivers an accuracy of 2.5 mm + 0.5 ppm RMS horizontally and 5 mm + 0.5 ppm RMS vertically.
How do the dual cameras assist in surveying?
The receiver features two cameras: a 2MP front camera designed for visual measurements and laser aiming, and a 5MP bottom camera optimized for AR stakeout, ensuring high efficiency in field operations.
What is the battery life and charging capability?
It features an internal 7.4V 7000mAh Li-ion battery. The device supports USB Type-C fast charging and provides up to 18 hours of operation in Rover mode, 7 hours in Base mode, and 20 hours in Static mode.
Is the receiver durable enough for harsh environmental conditions?
Yes, the device is built for rugged environments. It has an IP67 waterproof and dustproof rating, an IK08 vibration resistance, can survive a 2-meter pole-drop, and operates reliably in temperatures ranging from -45°C to +75°C.
