China AP80 Slices - Premium Quality from Trusted Suppliers and Reliable Factory
Satellites Tracking
| Channels | 1408 |
| GPS | L1C/A, L1C, L2C, L2P(Y), L5 |
| GLONASS | L1, L2, L3* |
| Galileo | E1, E5a, E5b, E6 |
| BDS | B1I, B2I, B3I, B1C, B2a, B2b |
| QZSS | L1C/A, L1C, L2C, L5, L6 |
| NavIC/IRNSS | L5 |
| SBAS | L1C/A |
| L-Band | B2B-PPP & E6-HAS |
Accuracy
| Real time kinematics (RTK) | H: 8 mm + 1 ppm RMS V: 15 mm+ 1 ppm RMS Initialization time: <5s(typical) Initialization reliability: >99.9% |
| Post-processing kinematics (PPK) | H: 3 mm + 0.5 ppm RMS V: 5 mm + 0.5 ppm RMS |
| Static | H: 2.5 mm+ 0.5 ppm RMS V: 5mm+ 0.5 ppm RMS |
| PPP | H: 5cm RMS | V: 10cm RMS |
| DGPS | H: 0.4 m RMS | V: 0.8 m RMS |
| Single Point | H: 1.5 m RMS | V: 2.5 m RMS |
| Visual survey | Typical 2~4 cm, range 2~15 m (normal lighting conditions) |
| Laser survey | ±8mm + 5mm/m ( Tilt angle within 30° ) |
| AR stakeout | H: 8 mm + 1 ppm RMS V: 15 mm+ 1 ppm RMS |
| Position Frequency | 1Hz 2Hz 5Hz 10Hz 20Hz |
| Time to first fix | Cold start <45s Hot start <10s Signal re-acquisition < 1 s |
| IMU tilt angle | 0-120° |
| IMU tilt survey accuracy | ≤2cm within 60° tilt angle |
Camera
| Number of cameras | 2 |
| Pixel | Global shutter 2MP & 5MP |
| Frame rate | 30fps |
| Field of view | 84° |
| Features | 2MP front camera achieve visual measurements & laser aiming 5MP bottom camera achieve AR stakeout |
Communication
| UHF radio | 2W Tx/Rx, 450-470 MHz Working range is 8-15km in ideal environments |
| Protocol | TT450, TRIMMARK3, SOUTH, LORA Link rate: 9600bps to 19200bps |
| Wifi | 802.11b/g/n/ac Hotspot/Data Link |
| Bluetooth | Bluetooth 5.2 classical/BLE proprietary dual-mode |
| NFC | NFC touch pairing |
| WebUI | Accessible via Wi-Fi |
| 4G Cellular | Integrated full frequency multi band 4G modem supports LTE-TDD/LTEFDD/WCDMA/CDMA2000/UMTS/HSPA+/GSM/GPRS/EDGE |
| I/O port | 1xUSB Type-C port (Data download / Charging) 1xAntenna port (UHF antenna interface) 1xSim card slot (Supports Nano-sim) 1x5-pin Lemo port (RS-232) |
| Data formats | RTCM 2.X, RTCM 3.X, RINEX, NMEA 0183 output, VRS, NTRIP |
| Data storage | 32GB high speed memory |
Electrical
| Battery | Internal Li-on Battery 7.4V 7000mAh |
| Charging specs | USB Type-C fast charging |
| Operation time | Rover mode: 18 hours Base mode: 7 hours Static mode: 20 hours |
Hardware
| Size | 125mm(W) 88mm (H) 4.92inch(W) 3.46inch(H) |
| Weight | 750g (1.65Ib) |
| Front panel | 0.96'' OLED color screen display 2 LED light, 2 physical buttons (switchable mode, data link) |
Environments
| Working temperature | -45°C to +75°C |
| Storage temperature | -55°C to +85°C |
| Humidity | 100% non-condensation |
| Waterproof & Dustproof | IP67 |
| Drop | Survive a 2-meter pole-drop |
| Vibration | IK08 |
Frequently Asked Questions
How many channels does this GNSS receiver support for satellite tracking?
This receiver features 1408 channels and supports comprehensive tracking of major satellite constellations, including GPS, GLONASS, Galileo, BDS, QZSS, NavIC/IRNSS, SBAS, and L-Band (B2B-PPP & E6-HAS).
What are the accuracy specifications for visual and laser surveying?
Visual surveying delivers a typical accuracy of 2 to 4 cm within a 2 to 15-meter range under normal lighting conditions. Laser surveying provides an accuracy of ±8mm + 5mm/m with a tilt angle within 30°.
Does the receiver support tilt compensation?
Yes, it is equipped with an IMU sensor that supports tilt angles from 0° to 120° and maintains a survey accuracy of ≤2cm within a 60° tilt angle.
What is the battery life and charging capability?
The receiver houses an internal 7.4V 7000mAh Li-ion battery supporting USB Type-C fast charging. It operates up to 18 hours in Rover mode, 7 hours in Base mode, and 20 hours in Static mode.
What camera configurations are integrated into the device?
The device features dual cameras with global shutters: a 2MP front camera for visual measurements and laser aiming, and a 5MP bottom camera designed for AR stakeout, both operating at 30fps with an 84° field of view.
How rugged is this device for harsh field environments?
It is built to withstand extreme environments with an IP67 waterproof and dustproof rating, IK08 vibration resistance, and the durability to survive a 2-meter pole-drop. Its working temperature ranges from -45°C to +75°C.
